100W (2COM 120V AC to12V/12V AC) Multi-Tap Low Voltage Transformer for Outdoor Landscape Lighting COT711P
Product Informations
About the COT711P Transformer
- It is durable and corrosion-resistant, designed to withstand rain, snow, dust, and corrosion over the long term, whether installed indoors or outdoors.
- Compatible with small or medium-sized 12V low voltage LED and halogen landscape lighting systems.
- Built-in photocell sensor and timer.
- Sliding lid design, makes it easier for you to adjust different Settings, and protects the switch of the transformer.
- We offer a lifetime warranty for this landscape light transformer.
4.38" × 7.5" × 4.5"
12V low voltage
110/120V AC, 50/60Hz
High Performance
With lifetime warranty and using state-of-the-art components, We stand behind our product with our top rated customer service
110/120V AC, 50/60Hz Input Voltage
Small Size
This low voltage landscape lights transformer is designed with 2 COM 120 Volt AC to 12/12 Volt, making it compatible with small or medium-sized 12V low voltage LED and halogen landscape lighting systems. It is widely used in outdoor landscape lighting, path lights, spotlights, deck lights, string lights, and more. we offer a lifetime warranty for this landscape light transformer. We stand behind our product with our top rated customer service. Please don't hesitate to contact us if you have any issues.
How to Choose Transformer
To determine the size of transformer needed for a low voltage lighting system, add up the wattage of all fixtures in the system and add 10% for lowvoltage cable and fixtures connections.
If the total load of fixtures is too great, either divide the total load between 2 transformers or use a more powerful transformer.
Select a transformer with 20% higher capacity than total wattage of all fixtures in the system, that allow you to add more fixtures later.
TRANSFORMER SIZING
SIZE OF TRANSFORMER=TOTAL WATTAGES OF FIXTURES X 1.1
Select a transformer that matches as close as possible to calculation shown above.
Example:you have 12 fixtures, each 5 watt. You need a 75 watt transformer (12x5=60 plus 10%= 66)
NOTE: Low voltage lighting systems require the use of a transformer to reduce the standard 120 volt power from ordinary household electricity to 12, 13, 14, and 15volt needed to power low voltage fixtures.
The total wattage of all fixtures connected to one transformer must not exceed the wattage capacity of the transformer.
How to Choose Transformer
To determine the size of transformer needed for a low voltage lighting system, add up the wattage of all fixtures in the system and add 10% for lowvoltage cable and fixtures connections.
If the total load of fixtures is too great, either divide the total load between 2 transformers or use a more powerful transformer.
Select a transformer with 20% higher capacity than total wattage of all fixtures in the system, that allow you to add more fixtures later.
TRANSFORMER SIZING
SIZE OF TRANSFORMER=TOTAL WATTAGES OF FIXTURES X 1.1
Select a transformer that matches as close as possible to calculation shown above.
Example:you have 12 fixtures, each 5 watt. You need a 75 watt transformer (12x5=60 plus 10%= 66)
NOTE: Low voltage lighting systems require the use of a transformer to reduce the standard 120 volt power from ordinary household electricity to 12, 13, 14, and 15volt needed to power low voltage fixtures.
The total wattage of all fixtures connected to one transformer must not exceed the wattage capacity of the transformer.
